1 Inch Leveling Kit Coil Spacer Ford F250/F350 Super Duty 05-16 4WD Suspension

Boost the front of your 2005-2016 Ford F250 and F350 Super Duty truck by installing this 1-inch coil spacer leveling kit from BDS. Designed to improve stance this kit includes everything necessary to set your truck up right with clearance for up to 33 inch Tires at an affordable price.

The lift kit includes billet aluminum coil spacers and custom-tuned NX2 Nitro or FOX Performance series shocks.

• Front Lift Method: Spacer
• Rear Lift Method: Stock
• Shocks Included: Yes
• Front Lift Height: 1 Inch
• Rear Lift Height: 0 Inch

• Easy, 100 percent Bolt-on installation
• Maintains factory like ride quality
• Standard NX2 Nitro shocks with vehicle-specific valving for better control
• Upgrade to FOX 2.0 Performance Series shocks for maximum performance on and off-road

Shock Option NX2 Nitro Series

• Nitrogen-charged
• Twin-tube design
• 10-stage velocity-sensitive valving
• Dual-welded ends for increased strength
• 1-3 8-inch high-flow piston
• Self-lubricating seals
• Silver powder coat finish

FOX 2.0 Performance Series

• 2-inch Impact extruded aluminum body
• Internal floating piston (Internal Floating Piston) monotube design
• CNC machined 6061-T6 aluminum mounting ends
• Massive 5 8-inch hard chrome plated heat-treated alloy steel shaft
• Race-developed high-flow piston design
• Application-specific valving to maximize performance
• Long-lasting clear anodized finish

Tire Size: 33 x 12.5 Tire Size 2: 33 x 12.5 Wheel Diameter: 18 x 9 Wheel Diameter 2: 20 x 9 Back Spacing: 4.5 4.5

Kit Components:

• Includes one BDS013101, 05-Up Ford F250 350 1in Spacer Kit, UPC Code 658848613045
• Includes two FOX98224660, Fox 2.0 Shock 30.05 x 18.45 x 2- EB1 EB1
• Includes two FOX98224710, Fox 2.0 Shock 23.27 x 14.65 x 2- S50 EB1
